Small Size Industrial Touch Screen Monitors
7" Industrial Monitor: Model: TPC070-M-QD
8" Industrial Monitor: Model: TPC080-M-QD
As the professional manufacturer, we would like to provide you high quality Small LCD Touch Screen. 7-inch and 8-inch small-size monitors with industrial-grade quality provide ideal touch display solutions for custom projects. These small LCD monitors are designed to fit anywhere and are made from an aluminum alloy so they're tough enough to take a beating.
Product Features
● 7" and 8" LCD screen panel option.
● 7-inch: 1024x600 native resolution, 16x9 Aspect Ratio
● 8-inch: 1024x768 native resolution, 4x3 Aspect Ratio
● Multi-point capacitive and 4/5-wiring resistive touchscreen support.
● Supports wide voltage input: 12V DC ~ 24V DC / 9V DC ~ 36V DC.
● VESA 75/100mm mounting holes.
● RoHS, FCC, CE Certification.
● 3-year warranty (36 months).
| Screen parameters | Screen Size | 7 inch / 1024*600 / 16:9 |
| 8 inch / 1024*768 / 4:3 | ||
| HDMI | HDMI*1 | |
| DVI | DVI*1 | |
| Power Interface | DC 12~24V | |
| Extended display | VGA*1, support for synchronous dual display and differential display | |
| Network interface | RJ45*1 | |
| Audio Interface | Audio I/O*1 | |
| I/O extensions | Support customization | |
| Display Parameters | Color | 16.7M |
| Point distance | 0.264mm | |
| Screen panel | Industrial control screen | |
| Contrast | 7" with 500:1 / 8" with 800:1 | |
| Display brightness | 300cd/m2 (high brightness customizable) | |
| View angle | (H)150 (V) 150, 178° wide viewing angle is customizable. | |
| Backlight type | LED-backlit screen Lifetime ≥ 50000h | |
| Gray-scale response time | 6.5ms | |
| Touch Optional | Resistive/Capacitive/Mouse Control | |
| Installation method | Embedded, desktop, wall-mounted, VESA | |
| Other Parameters | Power | 12V-5A Professional External Power Adapter |
| Power consumption | ≤60W | |
| Working temperature | -10°C～60°C | |
| Storage temperature | -20°C～70°C | |
| Relative humidity | 0%-65% (without condensation) | |
| Material | Full Aluminum alloy material | |
| Warranty Policy | Three-year warranty | |
| IP-rating protection | Front panel IP65 dustproof and waterproof | |
| Packing list | Industrial monitor / Mounting Accessories / Power Cord / Power Adapter / Driver CD / Manual / Warranty Card |
